Wilcoxon Sensing Technologies 726 Series Compact Piezoelectric Accelerometer

The Wilcoxon Sensing Technologies 726 series compact piezoelectric accelerometer is designed for long-term, reliable use. It is constructed with 316L stainless steel and features a 10-32 tapped hole for mounting with SF1 stud (included). It has a 10-32 coaxial output connector and R1 mating connector. The 726 is case grounded, and the 726T is base isolated.

The 726 series accelerometer is manufactured in an ISO 9001 facility.

Features

• Dynamic vibration (IEPE) sensor output
• Grounding:
  • 726: Case grounded, side connector
  • 726T: Base isolated, top connector
• 100mV/g sensitivity
• ±5% sensitivity tolerance
• 80g peak acceleration range
• Frequency response:
  • ±5%: 2 to 10,000Hz
  • ±10%: 1 to 12,000Hz
  • ±3 dB: 0.6 to 15,000Hz
• 32kHz resonance frequency
• 100Ω max output impedance
• 500g peak vibration limit
• 5,000g peak shock limit
