VEGA VEGAMET 862 Controller

The VEGA VEGAMET 862 controller feeds the connected 4 to 20mA or HART sensors, processes the measured values, and displays them. A large display for data visualization is integrated in the housing designed for rough field conditions.

The VEGAMET 862 enables a simple implementation of pump controls, flow measurements on open channels and weirs, totalizers, and data loggers, and difference, sum, and average value calculations. The VEGAMET 862 allows limit values to be reliably monitored and relays to be switched, for example, for an overfill protection according to WHG.

Features

• Two 4 to 20mA/HART sensor inputs
• Type of input (selectable):
  • Active input sensor supply through VEGAMET 862
  • Passive input sensor has own voltage supply
• Measured value transmission:
  • 4 to 20mA: analog for 4 to 20mA sensors
  • HART protocol: digital for HART sensors (not with passive input)
• Three 0/4 to 20mA, 20 to 0/4mA current outputs
• Relay output:
  • Six operating relays, one can be configured as fail safe relay
  • Switching voltage: max 250 V AC/60 V DC
  • Switching current: max 1 A AC (cos phi > 0.9), 1 A DC
• ATEX / Europe, c-UL-us, UKEX approvals
• IP66/IP67, Type 4X protection rating
• Bluetooth 5.0
• Simple and reliable commissioning and diagnosis of the measuring points via smartphone
• Easy-to-read display from a distance, even in sunlight and darkness
• Secure measurement data memory on SD card
