SolaHD SDU DC B Series DIN Rail UPS Power Supply

The SolaHD SDU DC B Series DIN Rail UPS Power Supply is an advanced 24VDC uninterruptible power unit that provides a wide operational temperature range. The UPS is a powerful, microprocessor controlled unit that provides protection from power interruptions. The 22.1 to 28.6VDC input voltage range provides an ideal power back-up solution for critical connected loads.

The SolaHD SDU DC B Series DIN Rail UPS Battery Module is a required accessory to this unit.

Applications
Industrial/machine control
Automation process control
Computer-based control systems
Conveying equipment
Material handling
Packaging machines
Semiconductor fabrication equipment
DeviceNet
Amusement park equipment
Pharmaceutical applications
Control rooms

Features

• 5 to 122°F temperature range
• Microprocessor based controls
• Automatic self-test feature for UPS function and battery management check
• Flexible batteries back-up expansion capabilities
• Overload protection in normal and battery modes
• User replaceable batteries
• IP20 rated input and output screw terminals
• No internal fan, no extra cooling required
• All metal DIN rail mounting connector
• LED status indicators
• Universal dry contact relay terminals provide remote signaling
• Monitoring, diagnostics, and remote turn-on and shut-off capabilities
