The Monarch VBX Vibration Stroboscope is uniquely designed to provide precise, instantaneous synchronization to a number of data collectors and FFT analyzers triggered by an accelerometer. Built for portable applications, the VBX is the perfect lightweight phase analysis tool. VBX allows for the measurement of phase without stopping the machinery to install reflective tape. Phase analysis is quick and accurate using the filter bandwidth selector and the relative phase adjustment. Unique “Tracking Filter” maintains phase lock to input pulse. VBX can power and be triggered by accelerometers with or without data collectors.
Full kit contents:
6220-033: Vibration Stroboscope – 30-50,000 FPM, with PSC-pbxU Power Supply/Recharger, 115/230 Vac, spare lamp with CA-4046-6 Accelerometer cable in Deluxe water tight, foam lined latching carrying case
6220-032: Vibration Stroboscope – 30-50,000 FPM, with PSC-pbxU Power Supply/Recharger, 115/230 Vac, spare lamp and SKF CMVA data collector interface cable with CA-4046-6 Accelerometer cable in Deluxe water tight, foam lined latching carrying case
6220-034: Vibration Stroboscope – 30-50,000 FPM, with PSC-pbxU Power Supply/Recharger, 115/230 Vac, spare lamp and CSI 2130 data collector interface cable with CA-4046-6 Accelerometer cable in Deluxe water tight, foam lined latching carrying case
6220-031: Vibration Stroboscope – 30-50,000 FPM, with PSC-pbxU Power Supply/Recharger, 115/230 Vac, spare lamp and CSI 2120 data collector interface cable with CA-4046-6 Accelerometer cable in Deluxe water tight, foam lined latching carrying case
