Mercoid 3200G Pressure Transmitter

The Mercoid 3200G Smart Pressure Transmitter is a microprocessor-based high performance transmitter, which has flexible pressure calibration, push button configuration, and programmable using HART® Communication. The Series 3200G is capable of being configured with the zero and span buttons, a field calibrator is not required for configuration. The transmitter software compensates for thermal effects, improving performance. EEPROM stores configuration settings and stores sensor correction coefficients in the event of shutdowns or power loss. The Series 3200G is FM approved for use in hazardous (Classified) locations. The 100:1 rangeability allows the smart transmitter to be configured to fit any application.

Features

• For compatible gases, steam, liquids or vapors
• Completely configurable using zero/span button (no calibrator required)
• Rangeability: 100:1 turndown
• High accuracy (±0.075%)
• Automatic ambient temperature compensation
• Fail-mode process function
• -40 to 248°F (-40 to 120°C) temperature limits
• Pressure range: -14.5 to 8500 psig
• Stability: ±0.125% FSO/yr
• Optional 5 digit LCD display
• 4 to 20 mA /HART Communications
• Electrical Connection: Two 1/2″ female NPT conduit, screw terminal
• Process Connection: 1/2″ female NPT
• Enclosure Rating: NEMA 4X (IP66) and explosion-proof for Class I, Div I, Groups A, B, C and D
• Agency Approvals: CE, FM
