Keller Valueline High Accuracy Pressure Transmitter

The Keller Valueline high accuracy pressure transmitter provides outstanding performance in new or existing pressure measurement applications. The Valueline can be calibrated to any pressure range between 2 and 15,000 psi with excellent Total Error Band (TEB) accuracy. It also provides a choice of analog outputs (current or voltage), which simplifies installation and ensures compatibility with most SCADA and PLC systems.

The Valueline pressure transmitter has been certified by UL to NSF/ANSI 61 and 372 standards for use in drinking water, and it is UL/cUL IS-approved for hazardous location applications.

Valueline models equipped with 4 to 20mA analog output include guaranteed lightning protection at no additional cost. This feature protects the pressure transmitter from fast-rising transients and carries a lifetime guarantee against damage from electrical surge making it perfect for installation in areas prone to chronic damage due to transients caused by lightning.

Features

• Accuracy includes non-linearity, hysteresis, & non-repeatability
  • ±0.1% (±0.05% optional) FS Static (25°C)
  • ±0.25% (±0.1% optional) FS Total Error Band (TEB)
• UL/cUL IS-approved
• NSF 61 and NSF 372 certifications (PE jacket only)
• 4-20mA includes guaranteed lightning protection
  • Lifetime warranty against voltage surges
• Ranges available from 0 to 2 up to 15,000 PSI
• 316L SS & Fluorocarbon wetted materials
• IP68 environmental protection with cable
  • IP65 with connectors
• 2-year warranty covers defects in materials & workmanship
• Built in the USA (ARRA Section 1605 Compliant); CE certified
