GEO Calibration 4000 EXP Humidity Generator and Calibrator

The GEO Calibration 4000 EXP humidity generator and calibrator is a vertical temperature and humidity generator that supports large calibration equipment. This unit features a temperature-controlled door, which is designed to maintain internal temperature and remain unchanged due to outside ambient temperature changes.

The 4000 EXP unit has a 3-5 minute response time and can perform automatic ramp/soak. Its 30 liter square chamber is suitable for calibrating data loggers, chart recorders, and probes, and the unit is also engineered to support legacy hair hygrometers.

Applications
Calibrating vertical systems

Suitable for harsh environments

Features

• ±5°C ambient temperature
• 10 to 90% RH humidity range at 23°C
• ±0.3°C temperature accuracy
• ±3.0% relative humidity accuracy
• PID Controller
• 0.3°C temperature uniformity at 23°C
• 3.0% RH uniformity at 23°C
• 0.2°C temperature stability
• 1% RH stability at 23°C
• Ramp/soak rate of change:
  • Temperature high to low, 0.50°C per minute
  • Temperature low to high, 1.00°C per minute
  • Humidity high to low, 1.00% RH per minute
  • Humidity low to high, 1.00% RH per minute
