Extech RPM33 Laser Photo Tachometer

The Extech RPM33 Laser Photo Tachometer quickly measures RPM, surface speed and length with one tool. Use the contact wheel for up-close readings or laser mode for safer, non-contact measurements up to 1.6ft (0.5m) away. The RPM33 has a large 5 digit backlit LCD display. The unit is microprocessor based with quartz crystal oscillator to maintain high accuracy. It provides wide RPM (photo and contact) and linear surface speed/length (contact) measurements. The non-contact laser can take measurements up to 1.6ft (500mm).

Applications for the contact RPM include:

Flywheels
Conveyors
Pumps
Elevators

Applications for the non-contact RPM include:

Motors
Fans
Gears

Features

• Photo mode range: 2 to 99,999rpm
• Contact mode range: 2 to 20,000rpm
• Accuracy: 0.05% rdg +1 digit
• Large 5 digit backlit LCD display
• Store/recall 10 data sets in memory
• Resolution:
  • 0.1rpm (less than 10,000 rpm)
  • 1rpm (greater than 10,000 rpm)
