Emerson PACSystems Rx3i Network Modules

Emerson PACSystems Rx3i network modules feature a variety of communications options for distributed control and I/O. Choose from PROFINET Controller, Ethernet EGD, PROFIBUS-DP, and DeviceNet. These high performance communication modules are easy to install, quick to configure, and can be provided as “in rack” solutions to reduce engineering design cycles and system complexity. In addition, communication capabilities up to the SCADA level and down to the device (IED) level improve connectivity, and time stamping capabilities deliver insight into operations to improve productivity and uptime.

Features

• PROFINET Module:
  • 10/100/1000M baud bus speed
  • Two RJ-45 and Two SFP Cages comm ports
  • 128Kb to 2880Kb of combined input/output memory
• DeviceNet Master Module:
  • CPU Rack back plane support
  • Screw terminal comm port
  • 500Kbaud bus speed
• PROFIBUS Module:
  • 12M baud bus speed
  • DB-9 connector comm port
• Ethernet Module:
  • SRT, Ethernet Global Data, Channels, Modbus TCP
  • Two RJ-45 ports one MAC Address
  • 10/100Mbaud bus speed
• Genius Bus Controller:
  • No Backplane Restrictions
  • Master
  • Screw terminal
