Dakota NDT PMX2-DL Thickness Gauge

The Dakota NDT PMX2-DL thickness gauge displays the thickness value of a wide range of materials with A and B-Scan displays. The auto find feature locates the detection point(s) and adjusts the display settings to bring the waveform into view. The gauge offers user-selectable resolution of either 0.01mm or 0.001mm (0.001/0.0001″).

Flexible & easy to use, the PMX2-DL  gauge is able to measure the thinnest point of the substrate with maximum precision. The high speed scan feature on the PMX2-DL speeds up the inspection process by taking 250 measurements per second. The transducer can be removed from the test material to display the minimum measurement scanned. Limits can be set for individual readings or for each batch with audible and visual alarms.

The PMX2-DL gauge offers the user a choice of display modes including Readings, Selected Statistics, Bar Graph, Run Chart & Differential Mode. As each measurement is taken, up to 4GB of readings and waveforms can be saved into the gauge memory as each measurement is taken, which can be downloaded later into an inspection application or into DakMaster Software for further analysis and reporting.

PMX2-DL Thickness Gauge Applications:
Precision machining
Stamping
Aircraft
Automotive
Thin plastics

Features

• 100MHz DSP platform with FPGA technology
• Measurement modes:
  • Pulse-Echo (P-E): contact transducers
  • Echo-Echo (E-E): contact transducers
  • Echo-Echo Verify: (E-EV): contact transducers
  • Interface-Echo (I-E): delay line and pencil transducers
  • Interface-Echo-Echo (I-E-E): delay line and pencil transducers
  • Pulser: square wave pulser with adjustable pulse width (spike, thin, wide)
  • Receiver: manual or AGC gain control with 110dB range
  • Timing: precision TCXO timing with single shot 100MHz 8-bit ultra low power digitizer
• Display views: A-Scan, B-Scan, Large Digits, Scan Bar, Bar Graph
• A-Scan display: + Rectified, – Rectified, Full Waveform (RF)
• B-Scan display speed: 10 to 200 readings per second
• Resolution (selectable): +/- 0.001in (0.01mm) or +/- 0.0001in (0.001mm)
• 64 custom user-defined setups
• Visual and audible alarm with high and low limit settings for specific application tolerances
• High speed scan: 250 readings per second
• 110dB gain range
• 4Gb internal memory
• Data management software
• 1/8in VGA (grayscale) display
• Factory calibration traceable to NIST & MIL-STD-45662A
