AEMC Model 607 TRMS Power Clamp On Meter

The AEMC Model 607 TRMS Power Clamp On Meter provides a new standard for safety and measurement capability not available in any other clamp meter sold today. Safety Rated at 1000V CAT IV, it is safe to operate in all electrical environments. It is rugged enough for the most demanding work environments and will withstand both dust and water spray with its IP54 rating. It is ergonomically designed and easily used by one hand, including function selection and button pushing even with a glove on. In addition to the standard measurement of volts, amps, frequency, resistance, diode checking and continuity, the Model 607 offers several unequaled functions including: AC, DC and AC+DC volts, amps and power, True InRush™, Power measurements, Harmonic analysis, Data logging and more.

Application include:

General purpose electrical troubleshooting
Motor start up analysis
Voltage troubleshooting
Bond and continuity checking
Phase sequence checking
Harmonic analysis
Power monitoring
Aircraft and ship board troubleshooting

Features

• IP54 Rated
• 10,000-count blue electroluminescent backlit display
• Measures up to 1000VAC (1400V peak)
• 1000VDC and AC+DC with resolution to 10mV
• Measures up to 2000AAC and 3000ADC
• Measures W, VA, var and PF for 1Φ & 3Φ balanced systems
• Measures single and three-phase power
• Measures frequency to 20kHz with 0.1Hz resolution
• Auto selects AC or DC measurement voltage
• UL 94 flame retardant self-extinguishing
• True InRush™ current measurement with 1mS capture
• Records up to 1000 measurements
• Wireless Bluetooth communications
• Jaw opening up to 2.36″
• Leads are constructed with a flexible silicone material
